Creep Rupture Test Didactic Equipment Vocational Education Equipment Mechanical Training Equipment

Item No.: WP 600
Creep Rupture Test Didactic Equipment Vocational Education Equipment Mechanical Training Equipment
Description
WP 600 Creep Rupture Test Didactic Equipment Vocational Education Equipment Mechanical Training Equipment

Demonstration of typical creep phenomena in various materials
Features
- typical phenomena of creep processes
- experiments at or below room temperature are possible
Learning objectives/experiments
- creep in specimens of various materials
- record a strain–time diagram (creep curve)
- influence of temperature and load on the creep
- load and recovery in plastics
Specification
[1] investigation of creep behaviour of different materials in creep rupture test
[2] constant load on the specimen via lever arm and stepped weights
[3] flat lead and plastic (PE) specimens
[4] experiments at or below room temperature are possible


[5] transparent temperature-controlled box with storage elements for cooling the specimen
[6] dial gauge for determining the elongation
[7] stopwatch to record time
Technical data
Specimens
- LxW: 25x5mm, thickness 2mm
- 10x lead
- 10x plastic (PE)
Weights
- 1x 1N (hanger)
- 2x 5N
- 3x 2N
- 3x 1N
- 2x 0,5N
Measuring ranges
- tension: 5...25N/mm2
- travel: 0...10mm, graduation: 0,01mm
- temperature: -50...300°C
LxWxH: 700x350x510mm
Weight: approx. 23kg
